Belleville Disc Springs

Belleville Disc Spring Washers are stackable supporting devices that support a desired load or travel. When used singly or in stacks, Belleville disc washers provide numerous applicable advantages when a specific load or travel distance is desired. Disc spring washers withstand extreme temperatures as well as corrosive environments. Belleville disc springs function positively within conditions that require very high load in confined space or short travel. Disc spring washers conform to the European standards DIN EN 16983 & DIN EN 16984 and are RoHS compliant.

Belleville disc spring washers are available in Carbon Steel, 301 Stainless Steel, 17-7PH Stainless Steel, and Inconel 718.

Products
Dimensional Specifications

Dimensional Specifications

Dimensional SpecificationsBelleville Disc Springs

STS Part Number	Diameter	Belleville Type	Grade	ID	OD	T	H	h	Load Rating	Load Rating lbs or N
STS Part Number	Diameter	Belleville Type	Grade	ID	OD	Thickness	Height	Deflection	Load Rating	Load Rating lbs or N
WBDS10X3.2X0.5-177	M3	Disc Spring	17-7 PH Stainless Steel	3.2004 mm	10.0076 mm	0.5080 mm	0.7620 mm	0.3302 mm	556	N
WBDS10X5.2X0.5-177	M5	Disc Spring	17-7 PH Stainless Steel	5.2070 mm	10.0076 mm	0.5080 mm	0.7620 mm	0.2540 mm	471	N
WBDS12.5X6.2X0.7-718	M6	Disc Spring	Inconel 718	6.1976 mm	12.4968 mm	0.7366 mm	0.9906 mm	0.2540 mm	934	N
WBDS15X7.2X1.25-301	M7	Disc Spring	301 Stainless Steel	7.1882 mm	15.1892 mm	1.2700 mm	1.9304 mm	0.2032 mm	2424	N
WBDS28X10.2X0.8ZN	M10	Disc Spring	50 CrV 4	10.2108 mm	27.9908 mm	0.7874 mm	1.7526 mm	0.9398 mm	723	N
WBDS20X10.2X1-718	M10	Disc Spring	Inconel 718	10.2108 mm	19.9898 mm	1.0160 mm	1.5494 mm	0.4826 mm	1695	N
WBDS25X12.2X1.5-718	M12	Disc Spring	Inconel 718	12.1920 mm	24.9936 mm	1.4986 mm	2.0066 mm	0.5080 mm	5960	N
WBDS40X16.3X1.5-177	M16	Disc Spring	17-7 PH Stainless Steel	16.3068 mm	40.0050 mm	1.4986 mm	2.7940 mm	1.3970 mm	3950	N
WBDS31.5X16.3X2-177	M16	Disc Spring	17-7 PH Stainless Steel	16.3068 mm	31.4960 mm	2.0066 mm	2.7432 mm	0.6350 mm	7806	N
WBDS31.5X16.3X2	M16	Disc Spring	50 CrV 4	16.3068 mm	31.4960 mm	2.0066 mm	2.7432 mm	0.7620 mm	8054	N
WBDS40X20.4X2.5-718	M20	Disc Spring	Inconel 718	20.3962 mm	40.0050 mm	2.4892 mm	3.3274 mm	0.8128 mm	10849	N
WBDS50X25.4X1.5-177	M25.4	Disc Spring	17-7 PH Stainless Steel	25.4000 mm	50.0126 mm	1.4986 mm	3.0988 mm	1.7018 mm	3340	N
WBDS50X25.4X3	M25.4	Disc Spring	6150	25.4000 mm	50.0126 mm	2.9972 mm	4.0894 mm	1.0922 mm	20683	N
